The Automatic Load Control Relay (ALCR) is a UL 924 listed emergency device that is powered from an always-available normal / emergency source fed by an upstream emergency transfer switch. The ALCR provides power to emergency lighting load(s) by bypassing switches or other controls upon loss of utility power and ensuring a "lights-on state" during loss of normal power while tracking the state of normal lighting loads during normal operation.



Features:

• Applications:
  • Conference Centers
  • Hotels
  • Dorms
  • Office buildings
  • Government buildings
  • Restaurants
  • Schools
  • Houses of worship
  • Theaters
• General:
  • 120V and 277V power systems
  • Automatically activates lighting upon loss of normal power
  • Provides remote activation by dry contact closure for connection to a fire alarm or building management system
  • Configurable "return-to-normal" delay of 0-15 minutes
  • Simple installation; fitted with a 1/2" nipple for permanent installation directly to an electrical junction box
  • Maintenance-free

Specifications:

• General:
  • UL 924 Listed
  • UL 2043 plenum rated
• Functional:
  • Automatic control of emergency power output to fixture or single-zone emergency lighting upon loss of normal power
  • Supports fire alarm input activation of emergency power output
  • Configurable return to normal delay settings of instant, 10 seconds, 30 seconds, 10 minutes, or 15 minutes
• Mechanical:
  • 1/2" conduit knockout mounted
  • Constructed of UL 94 V-0 approved injection-molded ABS
  • Remote and status LEDs
  • Two buttons shall be available to select optional return to normal delay and output test
• Electrical:
  • 120/277 VAC, 60Hz power input
  • Normally closed (NC), 20A fully-rated relay
  • 2 LEDs:
    • Red: Power (steady when active)
    • Green: Learn (blinks when active)
  • 12 AWG emergency power in and out wires on flying leads
  • 18 AWG sense and switch wires on flying lead
  • Remote activation switch can be located up to 1000 feet from ALCR
• Thermal:
  • Ambient room temperature: -10 to 45°C / 14 to 113°F
  • Ambient humidity: 5 to 95% non-condensing
• Physical:
  • Dimensions (L x W x H): 1.96 x 3.60 x 1.93" (50 x 92 x 50mm)
  • Product Weight: 0.875 lbs (0.397 kgs)
  • Shipping Weight: 0.95 lbs (0.431 kgs)
